RM-01

Modbus to wireless mesh network converter

RM-01 is a Modbus to wireless mesh network converter that can easily replace cabling in Modbus driven automation installations. The device can be mounted on a standard DIN rail and can be powered from a 12-28V DC source. It features an isolated RS-485/Modbus RTU interface and can seamlessly form a wireless mesh network with up to 4 network hops. The device includes dual antenna outputs for improved reliability and an advanced radio frequency front-end allowing successful operation even in the presence of strong electromagnetic interferences, typical for industrial environments.

Key features:

• Direct cable replacement for Modbus RTU installations
• 12-28 DC voltage power supply
• Full functional isolation between all ports
• Secure radio transmission
• Seamless operation in a wireless mesh network with multiple hops
• Quick installation and setup



• DIN rail mountable
• RS-485 interface with configurable baudrate
• License free 868MHz radio interface
• Dual antenna with antenna diversity for improved reliability
• Mini-USB configuration interface with a dedicated application



RCM-05 radio module

  • IEEE 802.15.4 compatible sub-GHz radio module, operating in license free 868MHz European frequency band
  • programmable output power up to +14dBm, with the possibility to compensate for antenna cable losses
  • supports dual antenna operation for improved reliability
  • suitable for long range communication in a multihop mesh network
  • C/C++/C#/JAVA/Python API library available
  • easy surface mount
  • industrial temperature range: -40 to +85°C
  • compatible with other RCM modules and RCG gateway
DocumentationBuy
rcg-01-a

RCG-01 commercial grade gateway

  • standalone gateway device, capable of managing a multihop mesh network
  • powerfull linux based embedded system
  • equipped with RCM-06 radio module
  • USB, Ethernet and RS-485 communication interfaces
DocumentationBuy
rcg-02

RCG-02 industrial grade gateway

  • standalone gateway device, capable of managing a multihop mesh network
  • powerfull linux based embedded system
  • equipped with RCM-06 radio module
  • USB, Ethernet and RS-485 communication interfaces
DocumentationBuy
3a

RCM-06 radio module

  • IEEE 802.15.4 compatible sub-GHz radio module, operating in license free 868MHz European frequency band
  • improved immunity to radio interference, and strong signal blocking
  • suitable for system targeting ETSI Cat1 compliance
  • programmable output power up to +14dBm, with the possibility to compensate for antenna cable losses
  • supports dual antenna operation for improved reliability
  • suitable for long range communication in a multihop mesh network
  • C/C++/C#/JAVA/Python API library available
  • easy surface mount
  • industrial temperature range: -40 to +85°C
  • compatible with other RCM modules and RCG gateway
Documentation

RCM Development Kit

  • the easiest way to start with the RCM modules
  • powerfull STM32F476 application microcontroller
  • includes all the necessary tools and example software
Documentation
